PDC580
PDC580 Dual-mode Rugged Radio
The PDC5 Series dual-mode rugged radio is a push-to-talk over cellular (PoC) radio, a DMR radio, a call recorder, and a voice gateway — all in one. It delivers instant, secure, and stable communications, empowering the professionals working in railway, security or electricity to keep safe and efficient, anywhere and anytime.
Highlights
Functions
DMR-PoC simul-call
The PDC690 features DMR-PoC Simul-call, so it can call both broadband devices and DMR radios simultaneously. This helps commanders save time and efforts to initiate the PoC and the DMR calls at the same time with the press of the PTT key.
All-round security assurance
The PDC690 can secure the voice and data through authentication, software and hardware encryption, or more. Trust Zone protects the system full-disk encryption (FDE) protects the user data air interface encryption (AIE) and end-to-end encryption (E2EE) protect the voice and data communication and remote control helps you manage radios.
Type-C
The Type-C port meets the needs of fast charging of devices. It can also be charged conveniently at the front-line combat site without the need to carry a traditional charger. Optional 4000mAh battery with long battery life supports all-weather outdoor operations.
Accessories for PDC580
Included as standard with PDC580
Antenna
Audio
Carrying
Battery
Mounting
Charger & Power
Cables
Related products that work with the PDC580
Technical Specifications
General
- Dimensions (H x W x D)
- 128 mm x 55 mm x 37 mm
- Weight
- 345 g
- Operating System
- RTOS
- Peripheral Interface
- USB Type-C port 13-pin accessory connector
- Card Slots
- 1x Nano SIM card
- Camera
- not supported
- Operating Voltage
- 7.7V (rated)
- Battery
- 3,000 mAh Li-Ion battery; 2,400 mAh smart battery (optional)
Wireless Data Communication
- Narrowband (DMR)
- VHF: 136-174MHz UHF: 400-470MHz
- LTE
- LTE-FDD: B1/3/5/7/8/20/28 LTE-TDD: B38/40/41
- GSM
- Not supported
- WLAN
- not supported
- NFC
- supported
- BT
- V5.3
- Positioning
- GPS, BDS, Galileo, GlONASS; TTFF (cold start) < 50s (CEP for 95%, –130 dBm); Horizontal accuracy < 5m (CEP for 90%, –130 dBm)
Transceiver
- Channel Spacing
- 12.5kHz/20kHz/25kHz
- TX Power
- 1W/5W
- Digital Vocoder Type
- AMBE+2™,NVOC
- Audio Power Output
- 1.5W
Environment
- ESD
- IEC 61000-4-2 (Level 4)
- ±8 kV (Contact)
- ±15 kV (Air)
- Dust & Water Protection
- IP67
- Humidity
- Per MIL-STD 810 H, ≤ +65°C, 95%RH
- Vibration,Drop&Shock
- MIL-STD-810 H
- Certification
- SRRC、CCC、CTA
